- Intelligent Analytics
- AI by NVRFacial recognition, perimeter protection, motion detection 2.0, AcuSearch, AcuSeek
- AI by CameraFacial recognition, perimeter protection, motion detection2.0, ANPR, VCA
- AcuSearch
- By Camera
All channels
*: The camera should enable AcuSearch function
- AcuSeek
- PerformanceIf the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling 50,000 targets/day.
- Search LanguageEnglish
- Perimeter Protection
- By NVR
Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarm.
Up to 4 MP: 2-ch;
5 MP to 8 MP: 1-ch
- By CameraAll channels
- Facial Recognition
- Facial Detection and AnalyticsFace picture comparison, human face capture, face picture search
- Face Picture LibraryUp to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 1 MB, total capacity ≤ 800 MB)
- Facial Detection and Analytics Performance
Up to 4 MP: 2-ch;
5 MP to 8 MP: 1-ch
- Face Picture Comparison8-ch
- Motion Detection 2.0
- By NVRAll channels, up to 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
- By CameraAll channels
- Video and Audio
- IP Video Input8-ch
- Incoming Bandwidth80 Mbps
- IP Speaker Input4-ch
- Outgoing Bandwidth160 Mbps
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output1-ch, 1920 × 1080/60Hz, , 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- CVBS OutputN/A
- Video Output ModeHDMI/VGA independent output
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input )
- Decoding
- Decoding FormatH.265, H.265+, H.264, H264+
- Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Synchronous Playback8-ch
- Decoding Capability
AI on: 2-channel 12 MP@30 fps, 3-channel 8 MP@30 fps, 4-channel 6 MP@30 fps, 6-channel 4 MP@30 fps, 8-channel 3 MP@30fps, 8-channel 2 MP@30fps
AI off: 4-channel 12 MP@30 fps, 6-channel 8 MP@30 fps, 8-channel 6 MP@30 fps, 8-channel 4 MP@30 fps, 8-channel 3 MP@30fps, 8-channel 2 MP@30fps
- Stream TypeVideo, Video & Audio
- Live View Window Division1/2/4/6/8/9
- Playback ModeNormal/Smart, Event, Tag, External File
- Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
- Network
- Remote Connection128
- APIONVIF (profile S/G); SDK; ISAPI
- Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- Interface8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power≤ 150W
- StandardIEEE 802.3af/at
- Auxiliary Interface
- SATA4 SATA interfaces
- CapacityUp to 16 TB capacity for each HDD
- Serial Interface2 RS-485 (half-duplex), 1 RS-232
- Alarm In/Out16/4
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- General
- GUI LanguageEnglish,Russian,Bulgarian,Hungarian,Greek,German,Italian,Czech,Slovakia,French,Polish,Dutch,Portuguese,Spanish,Romanian,Turkish,Japanese,Danish,Swedish,Norwegian,Finnish,Korean,TraChinese,Thai,Estonia,Vietnamese,Croatian,Slovenian,Serbian,Latvian,Lithuanian,Uzbek,Kazak,Arabic,Hebrew,Ukrainian,Indonesian
- Power Supply200 to 240 VAC, 50 to 60Hz
- Consumption≤ 50 W (without HDD)
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 to 90 %
- Dimension (W × D × H)440 × 391 × 72 mm (17.32 × 15.39 × 2.81 inch)
- ≤ 5 kg (without HDD, 11 lb.)
- Certification
- CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
- Obtained CertificationCE,CB,REACH,WEEE,UKCA,RCM,IC
